GFS series of high efficiency shredders
category：Crushing Equipment
product description：The machine is developed by the principle of mixed powdering method. It is suitable for pharmaceutical, food and chemical industry. The machine is simple in structure, easy to dismantle and disassemble the crushing chamber. The parts that are in contact with the material are made of stainless steel, which can be acid-resistant and make the material to be crushed more in line with the hygienic requirements. The machine is easy to move, smooth operation, low noise, good smashing effect, low power consumption.
Product Details
application:
The machine is developed by the principle of mixed dusting method. It is suitable for pharmaceutical, food and chemical industries. The machine is simple in structure, easy to dismantle and disassemble the crushing chamber. The parts that are in contact with the material are made of stainless steel, which can be acid-resistant and make the material to be crushed more in line with the hygienic requirements. The machine is easy to move, smooth operation, low noise, good smashing effect, low power consumption.
principle:
The machine is purely high-speed operation of the machine, using a fast mouth blade, the other side of the four-hit blade, so that the material was crushed by high-speed rotating blade cutting crushed. The machine can also be selected according to different materials of different sizes of different blades, the size of the size obtained by replacing the screen.
Technical Parameters:
|
model |
8 |
16 |
28 |
|
Motor Power(kw) |
3 |
7.5 |
11 |
|
Production capacity(kg/h) |
10-100 |
50-300 |
100-500 |
|
Rotating speed(rpm) |
4000 |
4000 |
4000 |
|
Finished fineness(含量≥85％) |
12-120mesh |
12-120mesh |
12-120mesh |
|
Outer dimension type A(mm) |
800×550×1250 |
900×660×1350 |
1000×750×1665 |
|
weight(kg) |
150 |
250 |
350
|
