CSJ series coarse grinder
category：Crushing Equipment
product description：This machine is suitable for pharmaceutical, chemical, metallurgy, food, construction and other industries. Processing of hard and difficult to crush the material, including plastic, copper, Chinese herbal medicine, rubber, etc. to crush, but also as a micro-grinder, ultra-fine grinding machine processing equipment before the process
Product Usage
This machine is suitable for pharmaceutical, chemical, metallurgy, food, construction and other industries. Processing of hard and difficult to smash the material, including plastic, copper, Chinese herbal medicine, rubber, etc. crushed, but also as a micro-grinder, ultra-fine grinding machine before processing the ancillary equipment.
working principle
The material is fed into the crushing chamber by the feed hopper, and the impact is cut by the blade and the tool holder. The rotating knife and the fixed knife are cut and crushed at the same time. The material is automatically discharged from the outlet due to the centrifugal force.
Technical Parameters
|
Model |
CSJ-250 |
CSJ-500 |
|
Feed size |
≤100 |
≤100 |
|
Discharge particles |
0.5-20 |
0.5-20 |
|
Spindle speed |
940 |
1000 |
|
Power |
4 |
11 |
|
Yield |
50-300 |
80-800 |
|
Dimensions |
860×650×1020 |
1120×1060×1050 |
