FL series boiling granulation dryer

category：Granulation Equipment

product description：FL series vertical boiling granulation dryer principle is the material powder particles, in the raw material containers (fluidized bed) in a circular fluidized state, by the purified heating air preheating and mixing, the adhesive solution atomization The particles are aggregated into aggregates containing the binder. As the hot air continues to dry the material, the moisture in the agglomerates evaporates and the binder solidifies. This process is repeated.

Order online


Product Details

Application areas

◎ Drug granulation and coating

Granulation: granules, granules, granules.

Coating: granules, pill protective layer, prepared color, sustained release, film, enteric coating.

◎ Food granulation and coating

Sugar, coffee, cocoa powder, cream, powdered juice, amino acids, seasonings, puffed food.

◎ Pesticides, Pigment Pigments, Dye Granules

◎ powder, granules, block material drying

Performance characteristics

◎ through the powder granulation, improve mobility, reduce dust flying;

◎ through the powder granulation, to improve its solubility;

◎ mixing - granulation - drying - in a machine to complete (one step granulation);

◎ use of anti-static filter, equipment, safe operation;

◎ adhesive atomizer with multi-fluid spray gun, uniform fog, finished product qualification rate greatly improved;

◎ equipment without dead ends, loading and unloading materials light and fast, rinse clean.

Schematic

1, the efficiency of the filter 2, the sub-high efficiency filter 3, the heater 4, the air valve 5, fluidized bed 6, infusion pump 7, compressed air 8, induced draft fan 9, silencer 10, shock absorber

Technical specifications

specification	3	5	15	30	45	60	90	120	150	200	300	500
capacity	12	22	45	100	155	220	300	420	530	660	1000	1500
Processing capacity	1.5/4.5	4/6	10/20	15/45	25/65	40/80	60/120	80/160	90/200	100/300	150/450	300/300
Fan power	2.2	3	4	5.5	7.5	11	15	18.5	18.5	22	30	37
Steam consumption	12	23	42	70	99	141	169	211	251	282	366	451
Compressed air consumption	0.3	1.3	0.3	0.4	0.4	0.6	0.6	0.9	0.9	0.9	1.3	1.5
noise	（Fan isolated installation）≤75
Dimensions	1.0 ×0.55 ×1.8	1.2 ×0.6 ×2.1	1.25 ×0.9 ×2.1	1.6 ×0.9 ×2.3	1.65 ×1.1 ×2.4	1.85 ×1.25 ×3	1.85 ×1.25 ×3	2.2 ×1.65 ×3.1	2.27 ×1.72 ×3.1	2.34 ×1.9 ×3.5	2.8 ×1.9 ×3.8	3 ×2.55 ×4.2
