Overview:
Powder coating granulation.
● spherical particles (pills) manufacturing.
Pill coating (film, enteric, protective layer).
● slow release coating, granulation.
Features:
● Finish the coating and granulation of the powder.
● finish powder, grain, pills taste, coloring.
● finish the powder coating to obtain the finished product is very high degree of ball.
● Finish the coating of the liquefaction of the powder, not easy to reunite, adhesion.
● The coating process of the powder is extremely reproducible.
● complete the powder coating for the amount of automatic control, the room temperature without splash.
● to complete the powder coating powder spray automatically, accurate measurement.
● Finish the coating of the powder The low density material can be treated due to the compaction of the centrifugal force.
● Finish powder coating granulation (pills), coating, dry once finished.
● Design and manufacture conforms to GMP specification, cleaning is quick, thorough and no cross contamination.
Model / item |
Feeding (kg / batch) |
Rotor speed (rpm) |
Rotor diameter (mm) |
Motor (kw) |
Fan power (kw) |
1300 |
60-90 |
0-150 |
1300 |
4 |
11 |
1000 |
30-50 |
0-180 |
1000 |
2.2 |
5.5 |
750 |
15-25 |
0-250 |
750 |
1.5 |
3 |
360 |
0.5-1.5 |
0-650 |
360 |
0.37 |
1.5 |
|
