EYH type two-dimensional motion mixer

category：Mixing Equipment

product description：Two-dimensional mixing machine mainly by the drum, swing frame, rack three parts. The drum is mounted on the swing frame and is supported by four rollers and axially positioned by two wheel wheels. In the four support rollers, two of the drive wheels are rotated by the rotating power system to rotate the drum, The swing frame is driven by a set of crank pendulum mechanisms, which are supported on the frame by means of a bearing assembly

Order online


Product Details

working principle

Two-dimensional mixing machine mainly by the drum, swing frame, rack three parts. The drum is mounted on the swing frame and is supported by four rollers and axially positioned by two wheel wheels. In the four support rollers, two of the drive wheels are rotated by the rotating power system to rotate the drum, The swing frame is driven by a set of crank pendulum mechanisms, which are supported on the frame by a bearing assembly.

Performance characteristics

EYH two-dimensional mixer of the drum can be carried out at the same time two movements, one for the rotation of the drum, the other with the swing with the swing frame swing. The mixed material in the drum with the drum rotation, flip, mixing at the same time, and with the drum swing occurred around the mixing movement, under the combined action of these two movements, the material in a short time to get the full the mix of. EYH two-dimensional mixer for all powder, granular material mixture.

Schematic

二维运动混合机结构示意图
Technical specifications

Specifications Model	Volume（L）	Loading factor	Loading weight （kg）	Dimensions（mm）						power（kw)
Specifications Model	Volume（L）	Loading factor	Loading weight （kg）	A	B	C	D	M	H	Turn	swing
EYH100	100	0.5	40	860	900	200	400	1000	1500	1.1	0.75
EYH300	300	0.5	75	1000	1100	200	580	1400	1650	1.1	0.75
EYH600	600	0.5	150	1300	1250	240	720	1800	1850	1.5	1.1
EYH800	800	0.5	200	1400	1350	240	810	1970	2100	1.5	1.1
EYH1000	1000	0.5	350	1500	1390	240	850	2040	2180	2.2	1.5
EYH1500	1500	0.5	550	1800	1550	240	980	2340	2280	3	1.5
EYH2000	2000	0.5	750	2000	1670	240	1100	2540	2440	3	2.2
EYH2500	2500	0.5	950	2200	1850	240	1160	2760	2600	4	2.2
EYH3000	3000	0.5	1100	2400	1910	280	1220	2960	2640	5	4
EYH5000	5000	0.5	1800	2700	2290	300	1440	3530	3000	7.5	5.5
EYH10000	10000	0.5	3000	3200	2700	360	1800	4240	4000	15	11
EYH12000	12000	0.5	4000	3400	2800	360	1910	4860	4200	15	11
EYH15000	15000	0.5	5000	3500	3000	360	2100	5000	4400	18.5	15
